MF
Mini servo feeder, 2'' wide, 0.062'' thick
The Azimuth MF mini servo feed is our most affordable feeding unit, handling narrow strip from 2 to 12 inches wide and up to 0.10 inches thick with ±0.004-inch feed accuracy at up to 20 in/s. Its low-profile OMRON SYSMAC servo drive fits tight press areas where a full-size feeder cannot, releases pneumatically on the press pilot signal, and runs stand-alone or integrated through a fully customizable HMI.
Choose options
MF
Sale price$0.00
| Maximum thickness | 0.125 |
| Minimun width | 0,5 |
| Maximum width | 19375 |
| Feed rolls diameter | 18125 |
| Feed accuracy | 0,000393701 |
| Straightener rolls diameter | 0 |
| Straighter type | Pull Thru (option) |
| Maximun coil weight | |
| Max COIL OD | 0 |
CORE TECHNOLOGY
Servo motorized system
Precision and Efficiency
Azimuth servo roll feeder utilizes a servo motor, which offers high precision in controlling the feed length and speed. This allows for exact positioning of the material, leading to accurate and consistent results.
Sequential feeding
GAG Built-in system
Our built in proamming allows you to sequential feed up to 20 sequences. Optional GAG relay output
Ease of integration
Built in integration
Introducing the Azimuth Servo Feed Interface: your seamless solution for integrating equipment and controlling your press-all from a single, user-friendly interface. Enhance your operational efficiency and simplify your workflow with our innovative technology. Upgrade your production process today!
